coosway | 放大倍率 | 物方 | 工作距 | 景深 | 遠心度 | 像方 | 像方最佳 | 像方最佳 | 像方畸變 | 物像距 | 相機接口 | 鏡頭總長 |
鏡頭型號 | β | FOV(Φmm) | WD(mm) | DoF(mm) | (° max) | CCD(Φmm) | F /# | MTF30 | (% max) | I/O (mm) | (mm) | |
GDCA230-66 | 0.166 | 66 | 166 | ±13 | ≤0.1 | 11.0(2/3") | 3.3 | >260lp/mm | ≤0.1 | 330 | C-Mount | 146.5 |
GDCA230-37 | 0.3 | 37 | 110 | ±4 | ≤0.1 | 11.0(2/3") | 3.75 | >230lp/mm | ≤0.1 | 273 | C-Mount | 145.5 |
GDCA230-37C | 0.3 | 37 | 110 | ±4 | ≤0.1 | 11.0(2/3") | 3.75 | >230lp/mm | ≤0.1 | 273 | C-Mount | 145.5 |
GDCA230-28 | 0.4 | 28 | 96 | ±2 | ≤0.1 | 11.0(2/3") | 5 | >90lp/mm | ≤0.1 | 230 | C-Mount | 116.6 |
GDCA230-22 | 0.5 | 22 | 65 | ±1.5 | ≤0.1 | 11.0(2/3") | 5 | >160lp/mm | ≤0.1 | 190 | C-Mount | 106.7 |
GDCA230-22C | 0.5 | 22 | 65 | ±1.5 | ≤0.1 | 11.0(2/3") | 5 | >160lp/mm | ≤0.1 | 190 | C-Mount | 106.7 |
